The New Type of Electric Hoist is a next-generation lifting device manufactured by Henan Mine, developed with advanced modular, lightweight, and intelligent design concepts based on European FEM/DIN standards while fully complying with GB/JB requirements . This hoist features a compact parallel structure with low headroom design (increasing effective lifting height by 200-500mm compared to traditional CD1/MD1 hoists), achieving 30% motor power reduction and over 20% improvement in operating efficiency while maintaining noise levels below 70 dB .

Key components include German imported variable pole motors (Class F insulation, IP54 protection), aluminum alloy reducer housing with lifelong lubrication (no oil change required), double-disc electromagnetic disk brake with self-adjusting clearance (1 million+ braking cycles), imported DAT high-strength carburized chains (wire rope models available), Grade V high-strength hooks, and Schneider or Siemens electrical components . The hoist supports four structural configurations (standard headroom running, low-headroom running, double-girner crab, and fixed), with intelligent features including inching movement, dead slow function, zero speed hover, electronic anti-sway (mm-level positioning accuracy), multi-hook coordination, and wireless connectivity for full lifecycle management via industrial internet platform . Typical specifications include lifting capacity from 0.08 to 80 tons (wire rope up to 32t, chain up to 10t, NHC series up to 80t), lifting heights from 3 to 30 meters (customizable to 60m), work duty M3 to M7, lifting speeds from 0.35 to 12 m/min, and ambient temperature from -20°C to +60°C .

It is mainly used for various lifting, pulling and loading/unloading of heavy objects. It can be installed independently on I-beams or in conjunction with electric or manual single-girder, double-girder, cantilever, gantry and other cranes for use.

Core Applications – New Type Of Electric Hoist 1.General Manufacturing Workshops – Lifts and positions machinery components, engines, heavy equipment, and assemblies on production lines and maintenance bays, with low headroom design maximizing lifting height in facilities with limited clearance .
2.Warehouses & Logistics Centers – Loads, unloads, stacks, and retrieves pallets, raw materials, and finished goods with quiet operation (<70 dB) and precise positioning, while energy-efficient motor reduces long-term operational costs .
3.Steel Service Centers & Metal Yards – Handles steel coils, plates, bars, structural sections, and pipes with heavy-duty M5-M6 configurations, using variable frequency drive for smooth, controlled lifting of sensitive metal materials .
4.Automotive & Heavy Equipment Assembly – Transfers car bodies, engine blocks, transmissions, and chassis components on assembly lines, with anti-sway technology ensuring vibration-free material flow and mm-level positioning accuracy .
5.Construction Sites & Precast Yards – Transports steel reinforcement, cement bags, precast concrete components, and construction materials, with fixed or running configurations suitable for both permanent and temporary installation .
6.Power Plants & Industrial Facilities – Performs equipment installation, pump and motor replacement, turbine maintenance, and general lifting tasks with high-duty M6-M7 cycles, utilizing corrosion-resistant options for harsh industrial environments .
