The Motor-driven Single Beam Suspending Crane, also known as the LX Model Electric Single Beam Suspension Crane, is a compact and efficient overhead lifting solution widely used for light to medium-duty material handling in industrial facilities. This crane is specifically designed with a suspension configuration, meaning the entire crane runs on the bottom flange of I-beam tracks suspended directly from the ceiling or roof structure, rather than on floor-mounted rails.

The crane consists of a single main beam (I-beam or box-section), two end carriages with traveling mechanisms, and an electric hoist (typically CD1 or MD1 type wire rope hoist) that travels along the lower flange of the main beam. The motor-driven traveling mechanism provides smooth longitudinal movement across the workshop, while the electric hoist handles the lifting and lowering of loads.

This crane is ideal for low-clearance workshops, warehouses, and assembly facilities where maximizing floor space is essential. The lifting capacity ranges from 0.5 to 10 tons, with spans from 3 to 22.5 meters (customizable up to 31.5m), and lifting heights up to 30 meters. The working duty class is typically A3 to A5, suitable for light to medium operational frequencies.

This suspension overhead crane is installed on building roof beams without occupying ground space. It is specially applicable for low factory buildings, small workshops, production lines and logistics warehouses. Ideal for light and frequent material handling operations in indoor ordinary working environments.

Core Applications:
1.Manufacturing workshops: Parts assembly lines, component handling, and production material supply
2.Warehouses and logistics centers: Loading, unloading, stacking, and moving finished goods and raw materials
3.Food processing industry: Handling raw materials and packaging finished products with hygienic operation
4.Assembly workshops and laboratories: Precisely positioned material handling and component assembly
5.Steel industries and machine shops: General-purpose lifting of metal components and materials
