The Hook Gantry Crane is a versatile, general-purpose rail-mounted lifting solution manufactured by Henan Mine, featuring a standard hook as the lifting attachment for handling a wide range of general cargo, machinery, pallets, containers, steel materials, and heavy loads in outdoor yards, warehouses, workshops, construction sites, logistics centers, and maintenance facilities. This crane consists of a main beam (box-type or truss), legs (L-type, U-type, or straight), a lower crossbeam with traveling wheels, an electric hoist (CD1/MD1 type or European-style hoist) or wire rope trolley as the hoisting mechanism, and an electrical control system with multiple control options including ground pendant, wireless remote, or cabin operation.

The crane offers flexible configurations including single-girder for light to medium duty (capacities 1-20 tons) and double-girder for heavy duty (capacities 5-100+ tons), with spans from 3 to 50 meters, lifting heights from 3 to 30 meters, working duty class A3 to A7, and ambient temperature range from -25°C to +40°C. Optional features include cantilever design on one or both ends, cable reel or sliding contact line power supply, variable frequency drive for smooth operation, anti-sway technology, weatherproof covers for outdoor use, and comprehensive safety systems including overload protection, dual limit switches, emergency stop, phase reversal protection, and short circuit protection.

Double-girder hook gantry cranes are large-scale loading machines widely used in open-air material handling. They have the advantages of large lifting capacity, large working space, high utilization rate of cargo yard area, low infrastructure investment and low operating costs. Therefore, it is widely applied in sectors such as industry and mining, transportation, and engineering construction.

Core Applications – Hook Gantry Crane
1.Outdoor Freight Yards & Warehouses – Loads, unloads, stacks, and retrieves pallets, steel coils, pipes, timber, containers, and general cargo in open-air storage yards, logistics centers, and rail freight terminals requiring versatile hook lifting.
2.Construction Sites & Precast Yards – Transports steel reinforcement, cement bags, precast concrete beams, panels, pipe piles, and construction materials in open staging areas, with mobile rail-mounted configuration allowing relocation as projects progress.
3.Steel Service Centers & Metal Yards – Handles heavy steel plates, coils, billets, structural beams, rebar bundles, and scrap metal in steel storage yards and fabrication facilities requiring high-capacity hook lifting and long spans.
4.Ports & Wharves – Loads and unloads containers, heavy machinery, industrial equipment, and general cargo from trucks, rail cars, and vessels in port back-up areas and small to medium-sized wharves.
5.Heavy Equipment Maintenance Facilities – Lifts and positions large machinery components, engines, generators, pumps, and industrial equipment for repair and overhaul in railway shops, power plants, and heavy industrial maintenance bays.
6.Manufacturing & Assembly Workshops – Handles raw materials, work-in-process components, and finished machinery in fabrication shops, assembly lines, and machine shops where building structures cannot support overhead bridge cranes.
