Electric single beam crane is composed of main beam, end beam, electric hoist and operating mechanism welded by steel plate and I-steel. The electric hoist runs along the lower flange of the main beam I-steel to complete the lifting of goods. It is currently the most widely used lifting machinery. It can load, unload and transport materials and equipment in a repetitive manner in general working environments, and has the functions of vertical lifting, longitudinal and lateral movement.It has the characteristics of light structure and convenient installation and maintenance. It is widely used in factories, warehouses, stockyards, etc.

There are three operation modes: ground handle, wireless remote control and cab(open/closed). The soft start motor and variable frequency speed regulation can be selected for the running motor according to the user's requirements. The crane starts smoothly and operates safely and reliably.

Electric single-girder cranes (hereinafter referred to as cranes) are currently widely used lifting machinery. Their lifting mechanism is an electric hoist, which can load, unload and transport materials and equipment in an intermittent and repetitive manner in general working environments. They have the functions of vertical lifting, longitudinal and lateral movement.

General machining workshops, warehouses, assembly workshops and renovation plants. Especially suitable for premises with low ceiling height.

Benefits & Features：
1.The product is highly mature, easy to install, and the modular design of the main beam and end beams allows for quick disassembly. Maintenance only requires periodic lubrication of the transmission components, resulting in low overall cost.
2.The structure is lightweight and has low wheel pressure.
3.The motor uses a Nanjing special conical rotor motor or a three-in-one drive unit, with low operating noise and a working class of A3-A5, which meets the requirements for medium-intensity work.
4.Sand blast for the whole crane steel structure, to make sure the paint is very strong.
5.Six action direction movement, to get enough working area.
6.Strong box type, one whole shape main beam welded by robot machine, very strong and beautiful.


Design Standard:
1. Mid- light duty of M4 (ISO)/1m(FEM);
2. Wheels, wire rope drum, gears, couplings are processed by CNC machine center, top quality control;
3. Heavy duty Conical squirrel cage motor with IP44,54/55, insulation class F/H
4. Electrical parts: Schneider main electric parts are used for durable and safe operation;
5. Standard single speed on the crane for speed controlling, but it could also be 2 speeds control (Normal/Creep speed).
6. Crane is equipped with all moving limit switch, loading limit and other standard safety devices, to promise crane work safe.
7. Long life span: 20-25 years;

Safety Devices:
1.Weight overload protection device.
2.Top quality long time bearing polyurethane materials buffer.
3.Lifting limit switch and traveling limit switch.
4.Emergency stop system.
5.Zero voltage protection.
6.Phases protection device.
7. High/low temperature resistance device.
