The Double Trolley Truss Gantry Crane is a high-performance, cost-effective lifting solution manufactured by Henan Mine, featuring two independent trolleys operating on a lightweight yet sturdy triangular truss structure welded from angle steel or I-beam, offering exceptional wind resistance, light dead weight, and simple construction for outdoor material handling operations.

This crane combines the operational flexibility of dual-trolley configuration (allowing both trolleys to work separately for dual-load handling or synchronize for coordinated lifting of extra-long loads) with the engineering advantages of truss design (strong wind resistance with wind pressure less than 125Pa, small windward side, easy installation and maintenance, and lower manufacturing cost compared to box-type gantry cranes).

The crane is used together with CD1, MD1, or other models of electric hoists, with each hoist traveling along the lower flange of the main beam's I-beam to complete lifting operations independently. Typical specifications include lifting capacity per trolley from 3 to 20 tons (combined up to 40 tons), spans from 12 to 35 meters, lifting heights from 6 to 12 meters, working duty class A3 to A5, working temperature from -20°C to +40°C, and control options including ground pendant, wireless remote, or cabin operation.

The Double Trolley Truss Gantry Crane features two independent trolleys on a single truss beam, allowing synchronized or separate operation. It is ideal for lifting extra-long loads like concrete beams, steel plates, or ship sections in precast yards, shipyards, steel centers, and bulk material storage. The truss design reduces weight and wind resistance, offering large span capacity (18–50m), outdoor durability, and higher handling efficiency.

Core Applications – Double Trolley Truss Gantry Crane
1.Outdoor Steel & Pipe Yards – Handles long steel pipes, structural beams, rebar bundles, and steel sections with two trolleys synchronizing from both ends for stable transport without bending, while truss design provides strong wind resistance for open-air yards.
2.Precast Concrete Yards – Transports extra-long concrete beams, bridge segments, pipe piles, and utility poles with dual-trolley synchronized lifting from multiple support points to prevent cracking, operating in windy outdoor fabrication areas.
3.Ports & Bulk Terminals – Loads and unloads general cargo, steel products, and construction materials from vessels and trucks, with lightweight truss structure allowing easy relocation and cost-effective operation compared to box-type designs.
4.Construction & Infrastructure Projects – Performs material handling for bridge construction, hydroelectric stations, and large-scale projects, with dual-trolley independent operation allowing simultaneous handling of different materials at multiple workstations.
5.Warehouses & Logistics Centers – Stacks and retrieves pallets, finished goods, and raw materials in semi-covered outdoor storage facilities where budget constraints favor truss over box-type designs and dual trolleys increase throughput.
6.Mining & Aggregate Yards – Moves ore, coal, sand, gravel, and bulk aggregates with two trolleys working independently to service multiple stockpile areas, while truss design provides excellent wind resistance for windy mining locations.
